LM Vertical slag mill

Online

LM Vertical slag mill

Input size

38-65mm

Production capacity

7-100T/H

Applications

Cement, electric power, metallurgy, chemical, non-metallic ore and other industries, focus on non-metallic minerals, coal and slag three major areas.

WhatsApp: 8619538445250

As a new type of high performance concrete admixture, slag powder has the advantages of improving various properties such as compressive strength, tensile strength, shear strength and bending resistance of concrete. At present, the use of slag powder to replace the cement content in concrete and cement products, has become the main trend of building materials industry. LM Vertical slag mill is a special equipment for grinding industrial waste into powder. Integrating drying, grinding, powder selection and conveying together, it is an ideal equipment for the slag powder production.

Working Principle

Drying the slag, then grinding the slag.

LIMING


Advantage

1. LM Vertical slag mill integrates drying, grinding, powder selection and conveying together, simple system, compact layout, the area is about 50% of the ball milling system. Reduce the cost of investment, low energy consumption, compared with the ball mill system, the energy consumption is 30% ~ 40%.

Model	Capacity (t/h)	Output fineness		Main mill power(kw)
Model	Capacity (t/h)	Micron(μm)	mesh	Main mill power(kw)
LM130N	7~11	170~45	80~325	200
LM150N	9~13	170~45	80~325	280
LM170N	11~15	170~45	80~325	400
LM190N	14~20	170~45	80~325	500
LM220N	22~26	170~45	80~325	800
LM240N	27~35	170~45	80~325	900
LM280N	48~55	170~45	80~325	1120
LM340N	65~89	170~45	80~325	1800
LM370N	90~100	170~45	80~325	2240
